ERICA MANUAL : VOLUME 15 LTR

  • Range :
    Electric
  • Code :
    ERM-WHT-V015
  • Description :

    The perfect storage water heater for small families

Disclaimer:
  • Jaquar reserves the right at its sole discretion, to change/modify/alter any product specification at any time without notice, where improvement can be effected in design, development and dimensions.
  • Although the information shown in this catalogue is updated to the extent possible but the same may vary. It is advisable to consult our local representative or check in a period manner for latest technical and other updates.
  • The prices are subject to change without notice and those ruling at the time of supply will be charged.
  • Colours & sizes of product images shown in the Website may vary in reality
  • read more...
Rated Wattage 2000
Volume(L) 15
High Pressure Rating 8 Bar
Outer body material ABS
Inner Contaner Thickness 2mm
Average Enamel layer thickness 0.35mm
Multi-function Safety Valve YES
Manual Lever YES
Heating element type Incoloy with Glass coated heating element
Warranty 7 Years on tank, 4 Years on Element and 2 years for other components
ELCB Facility Yes
Light/Temperature Indicators Power light
Voltage 230V~ 50Hz
Temperature Range 25-75ºC
Voltage 230V~ 50Hz
Shape Squarish
No of elements 1
Product Dimensions (in mm) 410x410x336
