Terra Semi - Digital Vertical 10 Ltr

  • Range :
    Electric
  • Code :
    TMV-WHT-V010
  • Description :
    The perfect storage water heater for small families
Disclaimer:
  • Jaquar reserves the right at its sole discretion, to change/modify/alter any product specification at any time without notice, where improvement can be effected in design, development and dimensions.
  • Although the information shown in this catalogue is updated to the extent possible but the same may vary. It is advisable to consult our local representative or check in a period manner for latest technical and other updates.
  • The prices are subject to change without notice and those ruling at the time of supply will be charged.
  • Colours & sizes of product images shown in the Website may vary in reality
  • read more...
Details Terra Semi - Digital Vertical
Volume(L) 10
Rated Wattage 2 Kw
Voltage / Frequency (V/Hz) 230V / 50Hz
Temperature Range 25ºC to 75ºC
Working Pressure (Mpa) 0.8
Inlet / Outlet Connection (Inch) 1/2
Outer Body Material ABS
Inner container material MS
Multi-function Safety Valve Yes
Heating element type Incoloy heating element
Warranty 7 Years on Tank,4 Years on Heating Element and 2 Years on Other Parts
Magnesium Anode Yes
Inlet / Outlet Material Stainless Steel
Thermostat  Yes
Thermal cut-out  Yes
ELCB  Yes
Display  Digital Display
Temperature Control Touch Panel
Shape Square
Installation Vertical
Product Dimensions (LxWxH in mm) 390 x 300 x 410
Net Weight  (Kg.) 7.5
